Between coil & contacts

Between open contacts

Between contacts sets

1000M Ω (at 500VDC)

5000VAC 1min

2000VAC 1min

2000VAC 1min

10kV(1.2/50μs)

30ms max.

10ms max.

70K max. (Contact load current 35A, rated voltage excitation 60%, at 85°C)

Shock resistance

Vibration resistance

Humidity

Ambient temperature

Termination

Unit weight

Construction

Functional

Destructive

98m/s²

980m/s²

10Hz to 55Hz 1.5mm DA

5% to 85% RH

-40℃ to 85℃

PCB

Approx. 66g

Flux proofed
