1A, 1C

Typ.: 20mV(at 10A)
Max.: 250mV(at 10A)

10A

15A

30VDC

1A 6VDC

See "CONTACT DATA"

1 x107 ops(300ops/min)

100MΩ (at 500VDC)

Dielectric strength4)

Operate time

Release time5)

Shock resistance6)

Vibration resistance6)

Ambient temperature

Termination

Unit weight

Construction

Between contacts: 750VAC
Between coil & contacts: 1500VAC

Typ.: 5ms
Max.: 10ms (at nomi. vol.)

Typ.: 3ms
Max.: 10ms

98m/s²

10Hz to 55Hz 1.5mm DA

-40C to 85°C

PCB7)

Approx. 10g

Plastic sealed, Flux proofed
