Contact arrangement | 1A | Operate time10) | Typ: 6ms (at nomi. vol.)
Max.: 10ms (at nomi. vol.) |
Voltage drop(initial) | Typ.: 30mV(at 10A)
Max.: 250mV(at 10A) | Release time10) | Typ.: 4ms
Max.: 7ms |
Max. continuous current1)10) | 70A(at 23°C); 50A(at 85°C) | Ambient temperature | -40C to 125°C |
Max. switching current10) | 70A | Vibration resistance6) | 10Hz to 55Hz 3mm DA
55Hz to 500Hz 100m/s² |
Max. switching voltage | 50VDC | Shock resistance5)10) | 294m/s² |
Min. contact load | 1A 6VDC | Flammability6) | UL94-HB or better(meetsFMvss 302) |
Electrical endurance | See "CONTACT DATA" | Termination | QC11), PCB7) |
Mechanical endurance | 1 x107 ops(300ops/min) | Construction | Plastic sealed, Dust protected |
Initial insulation resistance | 100MΩ (at 500VDC) | Unit weight | Approx. 38g |
Dielectric strength3) | 500VAC | Mechanical data11) | cover retention (pull&push): 200N min
terminal retention(pull&push): 100N min
terminal resistance to bending
(front&side): 10N min.9) |
