| Contact arrangement | 1A, 1C | Operate time10) | Max.: 7ms (at nomi. vol.) |
| Voltage drop(initial) | Typ.: 30mV(at 10A)
Max.: 250mV(at 10A) | Release time10) | max.: 5ms4) |
| Max. continuous current2) | 70A(at 23℃); 50A(at 85℃) | Ambient temperature | -40℃ to 125℃ |
| Max. switching current3) | 30A(Resistive) | Vibration resistance6) | 5Hz to 22.3Hz 10mm DA
22.3Hz to 500Hz 98m/s² |
| Max. switching voltage | 27VDC(Resistive) | Shock resistance5)10) | 294m/s² |
| Min. contact load | 1A 6VDC | Flammability6) | UL94-HB or better(meets FMVSS302) |
| Electrical endurance | See "CONTACT DATA" | Termination | QC7) |
| Mechanical endurance | 1 x106 ops(300ops/min) | Construction | Plastic sealed, Dust protected |
| Initial insulation resistance | 100MΩ (at 500VDC) | Unit weight | Approx. 35g |
| Dielectric strength3) | between contacts: 500VAC
between coil & contacts: 500VAC |
|
|
